14 section 5 - installation Instructions 5.1 Boiler Packaging The boilers are supplied in different packagings: Boiler Flue System (separate) Hardware Pack (separate) 5.2 Fitting/Mounting the Boiler Decide where the boiler is to be fixed on the wall, taking into account installation requirements detailed in previous section. Screw the wall mounting plate to the wall choosing one of the two sets of slots in left and right bank. Ensuring that at least one of the screws is fitted into a top slot. Example of fixing 5.4 internal wiring The boiler has been pre-fitted with a 3 amp fused approved moulded 3 pin and flying lead for use with 230V 50Hz.

You'll find all our brochures and manuals below. Arena 30 C Manual DOMIcompact F24 B Manual Domicompact F24 D Manual. Pegasus F2 E Manual. 1 GB24 & GB30 User & Installation Instructions off max e status burner mode reset. DHW/Preheat Control Knob C. CH Control Knob D. Boiler Status E. FERROLI F30 INSTALLATION, SERVICING AND USER INSTRUCTIONS. DOMINA 102 COPPER WALL-MOUNTED COMBINATION, GAS FIRED.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The plug should be used with an unswitched/shuttered socket outlet complying with BS1363. The boiler comes pre-fitted with a link wire between the room thermostat/timer connections on the terminal strip. This creates a permanent call for heat and must be removed when adding a room thermostat. Ringback tones. 4 Cable Clamp 2. Lift the boiler onto the wall mounting plate, locating it over the two tabs.

Room Thermostat - Wiring To fit a room thermostat proceed as follows: 1. Ensure that the electrical supply to the boiler is isolated before proceeding. Remove the two screws beneath the flap on the front of the boiler and lower the front panel. Remove the pre-fitted link wire between the Room stat/timer terminals. Pass the cable through a grommet, secure with the cable clamp and connect the room stat as shown in the diagram below.

If room stat has a neutral connection, connect this to terminal N (load) in the fused spur. Carry out all necessary electrical checks. Raise the front panel and relocate the two screws under the small flap. Check operation of room stat if possible. If present, remove the bottom end support packaging and ensure all plastic plugs are removed from CH & DHW connections. 5.3 Wiring InstruCTIons WARNING: THIS APPLIANCE MUST BE EARTHED Connections must be made in such a way that allows complete isolation of the electrical supply, e.g.

Double pole switch with 3mm contact separating in both poles. L N N Room Stat ROOM STAT/ TIMER 14 15 60 section 5 - installation Instructions 5.5 Water and Gas ConnectionS Ensure all boss blanking plugs are removed before making any connections. Each valve must be fitted to the correct boss as shown in diagram below Do not subject any of the isolating valves to heat as the seals may be damaged. Ensure that the green fibre washer is used on the CH flow connection. IMPORTANT - The gas service cock is sealed with a top hat washer - DO NOT subject to heat.

Pressure Relief Valve (PRV) - Located at the bottom right hand side of the boiler connection via a 15mm diameter stub pipe. Use a replaceable connection to ease the replacement of the valve if required. Ensure a safe discharge point using temperature and pressure resistant materials. 5.6 Air / Flue Systems The flue system is part of the appliance and is approved as such. Only use the flue systems supplied by Morco.

Template undangan pernikahan. Http-Version: 1.1 Status-Code: 200 Status: 200 OK Content-Type: text/html; charset=UTF-8 Expires: Mon, 22 May 2017 08:28:10 GMT Date: Mon, 22 May 2017 08:28:10 GMT Cache-Control: private, max-age=0 Last-Modified: Thu, 18 May 2017 03:34:12 GMT ETag: W/'9d9edef7cff152871aca1e13985abbee8f1d721c7607e1ab299e29' Content-Encoding: gzip X-Content-Type-Options: nosniff X-XSS-Protection: 1; mode=block Server: GSE Alt-Svc: quic=':443'; ma=2592000; v='37,36,35' Transfer-Encoding: chunked Domain Information.

The standard flue kit (RSF303) for the Morco GB range is a 600mm as shown below. There is also a 900mm kit available (RSF305). Turret 100 CH FLOW DHW OUTLET COND. DRAIN GAS INLET DHW INLET CH RETURN PRV Part No. RSF303 The minimum cut length is 138mm (includes 30mm into elbow) The maximum allowable length using extensions (RSF341) is: GB24-8m (minus any flue kit options) GB30-7m (minus any flue kit options) 15 16 section 5 - installation Instructions 5.7 determining THE flue length IMPORTANT. The boiler must be installed in a vertical position in accordance to the installation instructions.

Standard Flue Kits Horizontal Flue Terminal RSF303 (600mm long) - contains: Flue turret, non telescopic single piece flue incorporating a terminal and inner rubber wall seal. Extension Kit RSF341 - contains: 1 metre length of flue pipe (Functional length 950mm), 1 support bracket.

When extension kits are used the flue duct must incline 1.5 degrees away from the appliance, to allow the condensate to drain back to the boiler and out of the condensate drain. It is recommended that a support bracket is fitted on every 1 metre of pipe work used and the bracket is located as close to the collar as possible.
